Features
This watch winder will rotate your automatic watch to set direction and set Turns Per Day (TPD) to keep it wound.
It has five different TPD settings: 650, 900, 1200, 1500, 1800, with intermediate rest cycles to eliminate potential stress on watch movement. It rotates clockwise counter- clockwise, or alternates in between. The winder will repeat its cycle every day, without intervention (as long as it is on).
Functions:
LINE: Indicates active turntable.
MODE: Indicates rotation direction.
TPD: Indicates to number of Turns Per Day
Numbers displayed indicates active turntables.
* Left and right arrows will let you navigate between functions.
Once a function starts flashing that function is active.
* Up and down arrows will let you change settings for selected function.
* Center button will turn the tumtable on or off.
* LCD display for settings. * Touch control board.
* If a number is showing in the numbers display section that turntable is active.
* Optimal 8 turns per minute motor.

UL ROHS, CE, approved AC power adapter.
How to operate the watch winder * Pull watch holder out of turntable drum.
* Wrap your watch around it and place it back.
1. Plug the AC adapter to the wall outlet and the other end to the back of the watch winder.

2. Press right arrow until LINE function starts flashing.
3.Press up arrow to select the turntable you want to set
(if 0 is selected setting will apply to all).
4. Press right arrow to set the mode function, MODE function
will start flashing.
5. Press up arrow to select rotation mode Clockwise, Counter-
Clockwise, or Alternate.
6. Press right arrow to set the Turns Per Day (TPD) function,
TPD will start flashing.

7. Press up arrow to select preferred TPD 650, 900, 1200, 1500, or 1800.
8.Press on the center button to turn the turntable on.
Note:
When the line number appears on the far right side
of the LCD screen, that turntable is active. LCD light will turn off after 15 seconds. To turn LCD light on again press once on any button.
Standard Watch Winder Models:
Features pre-set programming. Models have choice of turning direction with predefined TPD (turns per day) program. Selected models have an additional dial for setting TPD of your choice.
Illustration:
OFF: Turn off
Clockwise
Counter-clockwise
OFF
III IV
: Alternating C&CC mode
1:650 TPD
II:750 TPD
III:850 TPD
IV:1000 TPD
Toggle Switch Models:
1. Clockwise mode with predefined TPD program
2. Turn off
3. ATL Alternating mode with predefined TPD program


Operation:
1. Plug the AC adapter into the back of the winder.
2. Determine how many turns per day (TPD) your watch requires, preset the winder by turning the TPD knob (selected models). Keep in mind that you can always use a higher TPD setting if the current setting does not wind the watch enough.
3. After setting the TPD, turn on the winder by selecting the rotary motion method for the watch, Clockwise mode, Counter-Clockwise mode or ATL Alternating C&CC mode.
4. Once the TPD and rotary motion method are selected, the motor can be left to wind the watch on its own. Our winders will automatically turn themselves on the next day at the same time. No human intervention needed.
5. The green LED light will turn on during operation, and will be flashing during rest periods, and turn off after the winder finishes winding.

Features:
•Automatically rotates watch in the set direction and set turns per day (TPD) in the correct turn and rest cycle.
•Adjustable TPD range (selected models) from 650 to 1000 with intermediate rest cycle to minimize potential stress to the watch movement.
•3 user select turning directions: clockwise, counter- clockwise, alternating (selected models).
•Automatic timer will turn itself on the next day at the same time. No human intervention needed.
•LED light indicator for operating and non-operating mode.
•Optimal 7 turns per minute motor and UL ROHS, CE, approved; AC powered.
•Exterior coated and polished with multiple layers of piano lacquer; Interior lined with deluxe fabric lining.
